632S - FOOT OPERATED SWITCH, CLIPPER SERIES, SPDT, (ON), 20 A, 250 V, 38.1 MM

Manufacturer: LINEMASTER
Manufacturer Part No: 632-S
Newark Part No.: 04M4757
Product Range: Clipper Series

The 632-S is a single-pole double-throw (SPDT) momentary clipper Foot Switch with screw terminals, non-skid base pad and adjustable strain relief connector. It features a cast aluminium housing painted Alert Orange with a splash resistant interior switch. It is designed with an ergonomic shape and cast iron housing that will stand the test of time. The wide treadle clipper switch offers the end user a 7-inch wide target to feel for when trying to depress the pedal. It is constructed of cast iron for long life.
· Durable black finish
· Proven reliability
· NEMA type 1 Enclosure ratings
· IP20 Protection rating

Applications: Industrial

Product Range: Clipper Series
Contact Configuration: SPDT
Switch Operation: (On)
Contact Current Max: 20A
External Height: 38.1mm
External Width: 88.9mm
External Depth: 114.3mm
