Product Overview
The BZ-2RD-A2 is a premium large standard Microswitch with overtravel plunger actuator for simple or precision on/off application. It features SPDT circuitry, 15A at 125VAC current rating, 2.5N to 3.61N (9oz-13oz) of maximum operating force and silver contacts with screw termination.
· Accepted world-wide standard large basic switch
· Low operating force and differential travel
· Long mechanical life up to 20000000 cycles at 95% survival
· Elongated mounting hole for easier, more accurate mounting
Applications
Industrial, Automotive, Test & Measurement, HVAC, Medical
Product Information
Microswitch Type: Standard
Microswitch Actuator: Overtravel Plunger
Contact Configuration: SPDT
Switch Terminals: Screw
Contact Current Max: 15A
Contact Voltage DC Nom: 250VDC
Product Range: BZ Series
Contact Voltage AC Nom: 125VAC
Operating Force Max: 3.61N
