CALEX CM2.15.200-115 DUAL POWER SUPPLY IN: 115V OUT: +/-15V at 200mA

CALEX CM2.15.200-115 DUAL POWER SUPPLY IN: 115V OUT: +/-15V at 200mA

PART NO. CM2.15.200-115
Distributeur
Calex
Prix normal
181.00 USD
Prix réduit
181.00 USD
Prix unitaire
par
Frais d'expédition calculés lors du passage à la caisse.

Part Category: Other Semiconductors
Manufacturer: Calex Mfg. Co., Inc.
Description: AC-DC Regulated Power Supply Module, 2 Output, Hybrid
REACH Compliant Yes
Analog IC - Other Type AC-DC REGULATED POWER SUPPLY MODULE
Input Voltage-Nom 115.0 V
Input Voltage-Min 103.5 V
Input Voltage-Max 126.5 V
JESD-30 Code R-XUFM-X5
Load Regulation-Max 0.04 %
Number of Functions 1
Number of Outputs 2.0
Number of Terminals 5
Operating Temperature-Min -25.0 Cel
Operating Temperature-Max 50.0 Cel
Output Voltage-Nom 15.0 V
Output Voltage-Min 14.925 V
Output Voltage-Max 15.075 V
Package Body Material UNSPECIFIED
Package Shape RECTANGULAR
Package Style FLANGE MOUNT
Qualification Status Not Qualified
Surface Mount NO
Technology HYBRID
Temperature Grade OTHER
Terminal Form UNSPECIFIED
Terminal Position UPPER
Additional Feature -15V ADDITIONAL OUTPUT AVAILABLE
