SKKD 100/16 - DIODE MODULE, 1.6 KV, 100 A, 1.35 V, DUAL SERIES, 3 PINS

Manufacturer: SEMIKRON
Manufacturer Part No: SKKD 100/16
Newark Part No.: 63K6161

Product Overview
The SKKD 100/16 is a SEMIPACK® 1 Rectifier Diode Module with heat transfer through aluminium oxide ceramic isolated metal baseplate and hard soldered joints for high reliability. The rectifier diode module features SKKD half bridge connection centre-tap connections and 1600V repetitive reverse voltage.
· UL Approval
Applications
Power Management, Motor Drive & Control
Warnings
Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.

Product Information
Repetitive Peak Reverse Voltage: 1.6kV
Average Forward Current: 100A
Forward Voltage Max: 1.35V
Diode Module Configuration: Dual Series
No. of Pins: 3Pins
Operating Temperature Max: 125°C
